MINI-TRENDS
VF8 DELTA/DELTA XL/KAPPA 6-7
The Interval key at the bottom left of the trend table display functions similarly to the
Hours feature in trend graphs (see page 6-4). Settings are
1, 5, 15, 30, or 60 min.
Mini-Trends
You can display up to one hour of trend data for as many as eight parameters while
continuing to monitor main screen waveforms and parameter boxes. Mini-trend
graphs follow the color coding and display order of the parameters they represent and
are updated with new trend data every 60 seconds.
To display Mini-Trends
1. Press the Fast Access fixed key.
2. Click on
Split Screen.
3. Click on
10 Min Trends, 60 Min Trends, Ventilation, or Off.
4. Press the main screen fixed key to exit the menu.
NOTE: The monitor always marks an NBP measurement and a C.O. average with a
time-stamp in the trend table.

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
