SYSTEM C OMPONENTS
VF8 DELTA/DELTA XL/KAPPA B-17
Medical Information Bus (MIB) II Duo Protocol Converter
(72 56 949)
MIB II Protocol Converter (72 56 931)
Physical Attributes
Connections:
Input: RS 232 25-pin D subminiature connector
Output, MIB II: RJ45 low speed MIB (IEEE 1073.3.2)
Output, MIB I: SDL high speed MIB (IEEE 1073.3.1)
Size (H x W x D):
29 x 84 x 170 mm (1.2 x 3.3 x 6.7 in)
Weight:
<0.4 kg (0.9 lbs)
Visual indicators:
2 LEDs
Cooling:
Convection cooled
Electrical Specifications
Power source:
DC powered, directly from Dräger IDS
Power consumption:
<4 Watts
Isolation:
Not Isolated
Mode of operation:
Continuous
Environmental Requirements
Temperature range:
Operating:10 to +40 °C (50 to 104 °F)
Storage: –20 to +50 °C (–4 to +122 °F)
Relative humidity:
Operating:20% to 90%, non-condensing
Storage: 10% to 95% (with packaging)
Atmospheric pressure:
Operating:525 to 795 mmHg (70 to 106 kPa)
Storage: 375 to 795 mmHg (50 to 106 kPa)
Physical Attributes
Connections:
Input: RS 232 25-pin D subminiature connector
Output: RJ45 Low Speed MIB (IEEE 1073.3.2)
Size (H x W x D):
29 x 84 x 170 mm (1.2 x 3.3 x 6.7 in)
Weight:
<0.4 kg (0.9 lbs)
Visual indicators:
2 LEDs
Cooling:
Convection cooled

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
