Dräger Infinity Delta User Manual

ST ANALYSIS SETUP
VF8 DELTA/DELTA XL/KAPPA 10-5
Quick Reference: ST Analysis Menu
Menu Item Description Settings
ST Monitoring Enables/disables ST monitoring.
NOTE: ST Monitoring is ghosted if
ECG is disabled or no leads are
connected.
•ON
•OFF
ST Lead1 Selects up to three ECG leads as
sources for ST analysis and display in
ST parameter box,
NOTE: All ST leads are monitored if
ARIES software is installed.
None, I, II, III, aVR, aVL, aVF, V
1
, V+
1
,
V1
1
, V2, V3
1
, V 4
1
, V5, V6
b
, dV1
2
,
dV3
2
, dV4
2
, dV6
2
, VM, CVM
ST Lead2
ST Lead3
ST Mini Trend Displays up to one hour of trended ST
data in mini-trend graphs on the left
side of the main screen.
NOTE: See page 6-7 for detailed
information about mini trends.
None, STI, STII, STIII, STaVR, STaVL,
STaVF, STV
1
, STV+
1
, STV1, STV2,
STV3, STV4, STV5, STV6, STdV1
2
,
STdV3
2
, STdV4
2
, STdV6
2
, STVM,
STVCVM
Relearn • Purges stored average S-T
complexes.
• Blanks average S-T complexes
currently displayed on the Measuring
Points screen.
• Learns the patient’s arrhythmia and
dominant QRS rhythm.
• Identifies the new dominant QRS
complex.
NOTES:
• New complexes are displayed on the
Measuring Point screen (see page 10-
6).
• Relearn is also accessible from the
ECG and ARR setup menus.
• All Relearn operations are stored in
the trends database. Markers on the
trend displays indicate when a
Relearn operation occurred.
Show All Leads Displays the waveforms of all
connected ECG leads, as well as
TruST leads
NOTE: Also accessible from the Main
menu/Review submenu and from the
All ECG fixed key on the remote
keypad).
When the Show All Leads screen is
displayed:
• Leads are displayed on a single
“page” except for 12-lead monitoring
leads (including TruST leads), which
are displayed six each on two pages.
• Parameter box display, alarm, and
recording functions are not affected.
• Rotary knob can only scroll Show All
Leads menu items.
• Parameter boxes are visible, but
inaccessible.
1
Selection unavailable/ghosted when TruST 12-Lead is set to ON.
2
Selection unavailable/ghosted when TruST 12-Lead is set to OFF.

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
