PATIENT P REPARATION
VF8 DELTA/DELTA XL/KAPPA 8-11
TruST Setup
You can select electrode configuration according to TruST twelve-lead format. TruST
twelve-lead monitoring is available Delta/Delta XL/Kappa only if you are using the
MultiMed 6-lead pod. If a five or twelve-lead pod is connected, the TruST 12-lead
selection is ghosted and unavailable.
To select TruST configuration:
1. Click on the HR parameter box.
2. Click on
ECG Options.
3. Scroll to
TruST 12-Lead and select ON.
Twelve-Lead Configurations (Standard and Frank)
You can select electrode configuration according to Standard or Frank Lead format.
Twelve-lead monitoring is available only if you are using the MultiMed 12-lead pod.
To select 12-lead configuration
1. Click on the HR parameter box.
2. Click on
Lead Setup.
3. Scroll to
12 Lead Position and select Standard or Frank.
Illustrations and guidelines for Frank and Standard lead configuration are provided on
the following pages.
NOTE: MultiMed 12-lead pod does not support Respiration.

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
