Dräger Infinity Delta User Manual

IBP
VF8 DELTA/DELTA XL/KAPPA 29-5
PiCCO Pod
1. Disconnect the pod from the monitor.
2. Clean the pod with a gauze moistened in enzymatic detergent or a solution of
green tinctured soap and water. Dry thoroughly with a lint-free cloth.
MPod – Quad Hemo
Agents tested by Dräger and shown to have no harmful effect at the time of testing on
the materials utilized in the MPod – Quad Hemo include:
— Isopropyl alcohol 40 %
— Compliance™; this cleaning agent may discolor soft plastic material
— Sporox II
— Dismozon pur
CAUTION:
 Do not use organic solvents.
 Do not sterilize by steam, heat, radiation or ETO.
 Do not use sharp objects.
 Make sure that NO liquid enters the pod.
CAUTION: Do not autoclave the MPod - Quad Hemo.
CAUTION: If using alcohol, it should only be a 40 % diluted solution. Higher
concentrations could damage the device.

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
