CONNECTING THE EEG POD
VF8 DELTA/DELTA XL/KAPPA 11-3
Connecting the EEG Pod
Connect the EEG pod to the monitor using the Hemo/Aux or Aux connector. For a
complete list of Dräger EEG accessories available with this product, see page C-20.
1 Lead diagram 6 Channel 1
2 Electrode connections 7 Neutral
3 Channel 4 8 “Trig” (area reserved for future
use; not yet functional)
4 Channel 3 9 Cable to monitor
5 Channel 2
