28-30 DELTA/DELTA XL/KAPPA VF8
28 P
ERIPHERAL DEVICES AND ASSOCIATED SOFTWARE
Caleo Status Messages
Dräger Babytherm Infant Warmer
The monitor, when connected to a Babytherm Infant Warmer via MIB, displays skin
temperature, mattress temperature and heater power in a parameter box on the
monitor.
There are two parameter boxes associated with the warmer, each with the ability to
display up to three parameters. The Warmer1 parameter box will be displayed by
default when the device is connected, and will be listed at the end of the parameter
priority list by default. However, the user will be able to select the warmer1 and/or
warmer2 separately from the parameter pick list depending on the number of
parameter boxes selected in the menu selection.
Message Condition Suggested Action
Duplicate Device
Connected
Multiple devices are
connected.
Make sure only one incubator is connected to
the monitor.
Tair Out of Range The Tair value is out of
range (high or low)
• Check the patient and treat, if necessary.
• Check the connections.
• Unplug and reconnect the incubator.
• Power-cycle the monitor or undock and redock
the monitor.
• Call the manufacturer.
T1skin Out of
Range
The T1skin value is out of
range (high or low).
T2skin Out of
Range
The T2skin value is out of
range (high or low).
Wt Out of Range The weight is out of range
(high).
R.H Out of Range The R.H value is out of
range (low).
%O2 Out of Range The %O2 value is out of
range (low).
NOTE:
The Babytherm Infant Warmer is only available in neonatal patient category.T1
skin and T2 skin are plotted on the same graphical trend channel.
Label Parameters Units
T1skin &
T2skin
Skin Temperature °C (°F)
Tmatt Mattress Temperature °C (°F)
HtrPwr Heater Power %
