SYSTEM C OMPONENTS
VF8 DELTA/DELTA XL/KAPPA B-9
Battery charge time: Internal: 6.5hrs. at 25°C
[For SC 7000/9000XL 4.5 hrs at25°C]
External: (Optional) 3.5hrs. at 25°C
Patient leakage current: 10 A
Mode of operation: Continuous with external power supply; for a limited time with battery
backup.
NOTES:
• Battery life varies with parameter configuration. The battery life specified above is under the
following load conditions: MultiMed
with SpO
2
sensor, 2 temperatureprobes, HemoMed pod with
4 IBP transducers and a catheter, NBP taking measurements every 15 minutes, LCD Transport
Brightness at 50%, and no continuous tone being generated.
• Advanced Communication Options are not supported during battery operation.
Environmental Requirements
Temperature range: Operating: 10 to 40 °C (50 to 104 °F)
Storage: –20 to +40 °C (–4 to +104 °F)
Relative humidity: Operating: 20 to 90 %, non-condensing
Storage: 1 to 95% (with packaging)
Atmospheric pressure: Operating: 525 to 795 mmHg (70 to 106 kPa)
Storage: 375 to 795 mmHg (50 to 106 kPa)
Protection against ingress
of water:
IPX1 (per IEC 60529)
Analog Output
Signals: ECG, arterial blood pressure (ART)
Delay: 25 ms
Output range: –5 V to +5 V
Signal gain: ECG: X 1000
ART: X 10 mV/mmHg
ECG bandwidth: 0.5 to 20 Hz (ESU filter mode)
0.5 to 40 Hz (other filter modes)
Pacemaker pulses: Amplitude: 5 V (nominal)
Duration: 4 ms
Rise time: <18 ms
Fall time: <20 ms
QRS Sync Output
Delay: 35 ms

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
