Dräger Infinity Delta User Manual

B-10 DELTA/DELTA XL/KAPPA VF8
B T
ECHNICAL DATA
Output high (QRS
detected):
Duration: 50 ms
Amplitude: +9 V ±5 % (nominal)
Source impedance: 5100 
Rise time: <7 µs
Fall time: <1 µs
Output low (no QRS): <0.8V @30 mA sink current
Pacemaker pulses: Not included
User Interface
Controls: Fixed keys and rotary knob
Alarms: 3 levels: High, Medium, Low
Screen
Type: Thin Film Transistor Liquid Crystal
(TFT-LCD) Display, Active Matrix.
Size: Delta: 264 mm (10.4 in) diagonal
Delta XL: 310 mm (12.2 in) diagonal
Viewing area: Delta: 211 x 158 mm (8.3 x 6.2 in)
Delta XL: 246 x 184.5 mm (9.7 x 7.3 in)
Resolution: Delta: 640 x 480 pixels
Delta XL: 800 x 600 pixels
Color capability: 512
Sweep speed: 6.25, 12.5, 25 and 50 mm/s ±10 %
Trend storage
Data storage: 24 hours of trended parameter information
Data resolution: 30 second sampling
Trend graphs: 1, 2, 4, 8, 12 and 24 hour display formats
Trend tables: 1, 5, 15, 30, and 60-minute display formats

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
