Dräger Infinity Delta User Manual

17-14 DELTA/DELTA XL/KAPPA VF8
17 P
ULSE OXIMETRY (SPO2)
Monitor Without Masimo or Nellcor Logo - Status Messages
Dräger OxiSure (via the MultiMed cables)
Message Possible Cause Suggested Action
SpO
2
> #
SpO
2
< #
The patient’s SpO
2
falls outside
the current upper or lower alarm
limits.
Check the patient and treat, if necessary.
PLS > #
PLS < #
The patient’s pulse rate falls
outside the current upper or
lower alarm limits.
SpO
2
< Low limit
value - 20%
The patient’s SpO
2
falls below
the current lower alarm limit by
20% or more.
PLS Out of Range
(Low/High)
The pulse rate is outside the
measuring range of the monitor
SpO
2
Transparent Too much light is reaching the
sensor’s light detector.
This condition usually occurs
because the sensor is off the
finger or because too much
ambient light is detected.
• Make sure the sensor is properly
attached to the patient’s finger.
• Remove the light source.
• Cover the sensor with opaque material.
• Make sure no ambient light can reach
the detector.
• Contact DrägerService.
SpO
2
Unrecognized
Sensor
The monitor does not recognize
the sensor connected as valid.
• Check for a defective or an unapproved
sensor.
• Replace the sensor.
• Contact the hospital’s technical
personnel or DrägerService.
SpO
2
Light Blocked Insufficient light is reaching the
sensor’s light detector.
NOTE: With detached or
partially detached disposable
sensors, the light emitters and
detectors may have become
misaligned.
• Make sure the sensor is properly
attached to the patient’s finger, and the
finger is free of blocking substances.
• Check for a defective sensor and
replace it, if necessary.
SpO
2
Artifact Persistent artifact • Make sure the SpO
2
sensor is properly
attached to the patient, the patient is not
moving, and all cables are properly
connected.
• Contact DrägerService.

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
