STATUS M ESSAGES
VF8 DELTA/DELTA XL/KAPPA 17-15
SpO
2
Weak signal The pulse amplitude is too low
due to of the following
conditions:
• Poor perfusion (shock).
• Low body temperature.
• Check the patient and treat, if
necessary.
• Make sure the SpO
2
sensor is properly
attached to the patient and all cables
are properly connected.
• Relocate the sensor to another
extremity.
• Contact DrägerService.
SpO
2
No
Measurement
The monitor has not been able
to compute a valid
measurement within the last 30
seconds because of unstable
measurement conditions.
• Make sure the SpO
2
sensor is properly
attached to the patient at a site free of
patient motion and all cables are
properly connected.
• Contact DrägerService.
SpO
2
Regulation
Error
• Inconsistent light level
• Excess ambient light
• Make sure the SpO
2
sensor is properly
attached to the patient.
• Remove or shade any external sources
of light entering the sensor.
• Contact DrägerService.
SpO
2
Unplugged The sensor cable is not
connected to the MultiMed pod.
• Make sure the cables are securely
connected.
• Check for a defective sensor.
SpO
2
: non-Masimo
compatible sensor
A non-Masimo compatible
sensor or SpO
2
pod is
connected to a monitor that is
configured for Masimo.
• Replace with a Masimo-compatible
sensor.
• Contact the hospital’s technical
personnel (SpO
2
compatibility is a
locked option).
SpO
2
: non-Nellcor
compatible sensor
A non-Nellcor compatible sensor
or SpO
2
pod is connected to a
monitor that is configured for
Nellcor.
• Replace with a Nellcor-compatible
sensor.
• Contact the hospital’s technical
personnel (SpO
2
compatibility is a
locked option).
Incompatible SpO
2
Cable (does not
apply to 12-lead
pod)
The SpO
2
cable part # 33 78
614 is no longer supported.
Replace with compatible SpO
2
cable (For
a complete list of Dräger provided SpO
2
accessories available with this product,
see page C-13).
Duplicate Device
Connected
The MultiMed pod (with SpO
2
sensor) and Infinity Masimo SET
pod or Infinity Nellcor Oximax
pod are connected
simultaneously.
Disconnect the duplicate device.
Message Possible Cause Suggested Action

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
