Dräger Infinity Delta User Manual

B-18 DELTA/DELTA XL/KAPPA VF8
B T
ECHNICAL DATA
Displays
Display Unit (Kappa only)
See user manuals for the video monitor you are using. Dräger Medical recommends TFT Medical
Grade 15”/17”/19” display. The requirements for the Kappa flat panel are as follows.
Electrical Specifications
Power source:
DC powered, directly from Dräger IDS
Power consumption:
<4 Watts
Isolation:
Not Isolated
Mode of operation:
Continuous
Environmental Requirements
Temperature range:
Operating:10 to +40 °C (50 to 104 °F)
Storage: –20 to +50 °C (–4 to +122 °F)
Relative humidity:
Operating:20 to 90 %, non-condensing
Storage: 10 to 95 % (with packaging)
Atmospheric pressure:
Operating:525 to 795 mmHg (70 to 106 kPa)
Storage: 375 to 795 mmHg (50 to 106 kPa)
VGA Display
Output resolution:
High resolution mode: 1024 x 768
Medium resolution mode: 800 x 600
Low resolution mode: 640 x 480
Horizontal frequency:
High resolution mode: 35.5 kHz
Medium resolution mode: 37.9 kHz
Low resolution mode: 31.5 kHz
Vertical frequency:
High resolution mode: 87 Hz (interlaced)
Medium resolution mode: 60 Hz (non-interlaced)
Low resolution mode: 60 Hz (non-interlaced)
Video signal level:
1Vpp
Sync. signal level:
High resolution mode: TTL (positive)
Medium resolution mode: TTL (negative)
Low resolution mode: TTL (negative)
Isolation:
Galvanically isolated from IDS in accordance with IEC 60601-1-1

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
