B-8 DELTA/DELTA XL/KAPPA VF8
B T
ECHNICAL DATA
System Components
Delta/Delta XL Base Unit
Physical Attributes
Size (H x W x D):
(without modules)
Delta: 253 x 365 x 190 mm (10.0 x 14.4 x 7.5 in)
[SC 7000:224 x 330 x 102 mm (8.8 x 13.0 x 4.0 in)]
Delta XL: 272 x 384 x 190 mm (10.7 x 15.1 x 7.5 in)
[SC 9000XL:254 x 360 x 190 mm (10.0 x 14.2 x 7.5 in)]
Weight: Delta: Without external battery:5.8 kg (12.7 lb)
[SC 7000:Without external battery:7.0 kg (15.5 lb)]
Delta: With external battery:6.4 kg (14.0 lb)
[SC 7000:With external battery:7.7 kg (16.9 lb)]
Delta XL:Without external battery:6.2 kg (13.6 lb)
[SC 9000XL:Without external battery:7.7 kg (16.9 lb)]
Delta XL:With external battery:6.8 kg (14.9 lb)
[SC 9000XL:With external battery:8.3 kg (18.3 lb)]
Cooling: Convection
Enclosure: Plastics: ABS/PC, FR 110
Printed circuit boards: Board: Glass/epoxy Fr4
Solder: Lead/tin
Copper etch
Lithium battery
Heatsink assemblies: Cast magnesium alloy
Internal battery: Lithium Ion
NBP assembly: Silicon tubing, steel, copper wire
Electrical Specifications
Input voltage: 11 to 15 V DC
Power consumption: 70 Watts (fully loaded)
Protection class: Internally powered (per IEC 60601-1) and for use with specified
Class 1 power supplies.
Battery voltage range: Internal: 9.8 - 13.6 VDC
External: (Optional) 13 - 17 VDC
Battery life: 180 minutes (230 minutes with optional External Battery)
[For SC 7000/9000XL 75 minutes (125 minutes with optional external
battery)]
NOTE: Battery life varies with parameter configuration. The battery
life specified above is under the following load conditions: MultiMed
with ECG leads and SpO
2
sensor, 2 temperature probes, HemoMed
pod with 4 IBP transducers and a catheter, NBP taking
measurements every 15 minutes, LCD Transport Brightness at 50%,
and no continuous tone being generated.
