Dräger Infinity Delta User Manual

21-24 DELTA/DELTA XL/KAPPA VF8
21 R
ESPIRATORY MECHANICS
Status Messages
Message Condition Suggested action
PIP > # The PIP value is above the alarm limits.
NOTE: A PIP alarm can only occur if a valid
sensor is connected and the PIP alarm has
been enabled.
Check the patient and the
ventilator settings.
PEEP > #
PEEP < #
The PEEP value is above or below the alarm
limits.
NOTE: The PEEP and MVe alarms are not
available until a sensor is connected and a
valid Respiratory Rate (RRv) becomes
available.
Check the patient and the
ventilator settings.
MVe < # The MVe value is below the alarm limit.
NOTE: PEEP and MVe alarms are not
available until a sensor is connected and a
valid Respiratory Rate (RRv) becomes
available.
Check the patient and the
ventilator settings.
RRv: APN An apnea based on flow measurements Check the patient and the
airway circuit.
Flow:
• Adult/Pediatric
Sensor
• Pediatric Sensor
• Neonatal Sensor
Indicated Flow or CO2/Flow sensor
connected.
Verify that the flow or the
etCO
2
/flow sensor type
matches the patient
category.
Flow: Invalid Sensor An unknown sensor is connected. Replace the sensor.
Flow: Purge in
Progress
Purging flow sensors and tubing. None
Flow: Unable to Zero;
Purge Sensor
Flow or pressure sensor zero failed. • Check the tubing.
• Initiate manual purge.
Flow: Sensor
Disconnected
Flow sensor is disconnected. • Connect the sensor.
• Check the airway circuit.
Flow:
H/W Problem
Hardware failure. • Contact DrägerService
representative.
Flow: Purge Timeout Purge time has exceeded standard limits. • Check the tubing.
• Initiate a manual purge.
CO2/Flow Pod
Disconnected
The etCO
2
/Respiratory Mechanics pod is
disconnected.
Connect the pod.
Duplicate Device
Connected
A device that duplicates the pod’s monitoring
capabilities is connected.
Disconnect the duplicate
device.

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
