Dräger Infinity Delta User Manual

28-24 DELTA/DELTA XL/KAPPA VF8
28 P
ERIPHERAL DEVICES AND ASSOCIATED SOFTWARE
Dräger Infant Incubator C2000/C2000e
The monitor, when connected to a C2000/C2000e infant incubator via MIB, displays
skin temperature, air temperature, humidity, oxygen levels and weight in a parameter
box on the monitor.
There are two parameter boxes associated with the incubator, each with the ability to
display up to three parameters. The Incub1 parameter box appears by default when the
device is connected. However, the user can select Incub1 or Incub2 separately from
the parameter pick list depending on the number of parameter boxes selected in the
menu selection.
To access the Infant Incubator: C2000/C2000e Setup menu
 Click on the Incub1/Incub2 parameter box main screen.
or
1. Press the
Menu fixed key.
2. Click on
Patient Setup.
3. Click on
Parameters.
4. Click on
Incub1/Incub2.
NOTE:
 The C2000/C2000e Infant Incubator is only available in neonatal patient
category.
 T1 skin and T2 skin are plotted on the same graphical trend channel.
Label Parameters Units
Tair Air Temperature °C (°F)
T1 skin &
T2 skin
Skin Temperature °C (°F)
Wt Weight g (oz)
R.H Humidity %
%O2 Oxygen %

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
