Dräger Infinity Delta User Manual

IBP SETUP
VF8 DELTA/DELTA XL/KAPPA 14-13
IBP Setup
IBP setup is a two-phase process involving the following procedures. After
configuring individual IBP parameters, you must assign them to connected IBP
channels.
To access an IBP parameter setup menu
 Click on the respective parameter box on the main screen;
or
1. Press the
Menu fixed key to display the Main menu.
2. Click on
Patient Setup.
3. Click on
Parameters.
4. Scroll to the IBP parameter you want to configure (ART, LV, PA, RV, CVP,
RA, LA, ICP, ICP2, ICP3, ICP4, GP1, or GP2) and click. The setup menu
appears, with the name of the parameter you have selected displayed at the top
of the menu.
Quick Reference – IBP Setup
Available functions, present on all IBP setup menus, are described in the following
table:
IBP Setup Menus
Menu Item Description Available Settings
Zero Zeroes the transducer and displays
time and date of last zeroing operation
(see page 14-3).
Not applicable (read-only)
Scale Sets the upper values of the IBP
waveform scale.
• ART, CVP, LV, GP1, GP2, ICP,
ICP2, ICP3, ICP4, LA,
P1-3 (a-d), PA, RA and RV: 5,
10, 15, 20, 25, 30, 35, 40, 50,
75, 100, 125, 150, 175, 200,
225, 250, and 300 mmHg
Filter Adjusts the filter applied to the IBP
signal.
8, 16, and 32 Hz
Cal Factor Determines the calibration factor. 80 – 120
Last Cal Factor Displays the time of the last successful
calibration.
Not applicable (read-only)

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
