EEG SETUP
VF8 DELTA/DELTA XL/KAPPA 11-7
Quick Reference
– EEG Setup
The following table describes available EEG setup functions.
Menu Item Description Available Settings
Lead Label Allows you to select a lead label
according to the current
measurement mode (differential or
referential) – see page 11-4.
NOTE: Proper skin preparation and
careful electrode positioning are
essential for reliable results in EEG
monitoring. Follow the same
recommendations as for ECG
monitoring (see page 8-8).
You can select either a generic or a
specific site label. If you select a specific
site label, the cursor moves to the other
half of the pair. Choose another site label
and click to confirm.
• Generic site labels: None, Left, Right,
Front, Back, Left Front, Left Back,
Right Front, Right Back
• Specific site labels: Fp, Fp1, Fp2, Fz,
F3, F4, F7, F8, Cz, C3, C4, T7, T8, Pz,
P3, P4, P7, P8, O, O1, O2
NOTE: Refer to the diagram on top of the
EEG pod for site locations.
Size Determines the amplitude of each
EEG waveform.
• 5, 10, 25, 50, 100, 250, or 500
µV
Size ALL Determines the amplitude of all EEG
waveforms simultaneously.
• 5, 10, 25, 50, 100, 250, or 500
µV
EEG Channels Allows you to display up to 4
channels for EEG monitoring.
• 1, 2, 3, and 4
EEG Options Opens new menu with selections for
EEG related settings.
NOTE: See “EEG Options Submenu”
below.
• Parameter 1
• Parameter 2
• Parameter 3
• EEG MiniTrend
• SEF Setting
• Low Filter
• High Filter
• Notch Filter
1
Selection is grayed out if EEG pod is
software version VE0.
Power Spectra Shows frequency distribution data for
channels selected on EEG setup
menu.
Not applicable
NOTE: The power spectra display
consists of 4 histograms showing the
frequency distribution for each channel,
plus all 8 derived parameters for each
channel.
