12-18 DELTA/DELTA XL/KAPPA VF8
12 R
ESPIRATION
Status Messages
Message Possible Cause Suggested Action
RESP > # The respiration rate is above the
upper alarm limit.
Check the patient and treat, if necessary.
Check the placement of electrodes. Change
their position, if necessary.
Move the electrodes away from the source
of interference.
RESP < # The respiration rate is below the
lower alarm limit.
Check the patient and treat, if necessary.
Check the placement of electrodes. Change
their position, if necessary.
RESP Out of
Range (High)
The respiration rate exceeds
150 breaths per minute.
The monitor may be counting
artifacts as valid breaths.
The monitor may be counting
interference caused by faulty
equipment.
Check the patient and treat, if necessary.
Check the placement of electrodes. Change
their position, if necessary.
Move the electrodes away from the source
of interference.
RESP Apnea
(neonatal or
pediatric mode
only)
No respiration has been
detected for <XX> seconds.
Check the patient and treat, if necessary.
Check the placement of electrodes. Change
their position, if necessary.
Carry out a RESP relearn.
Reset breath-detection sensitivity to manual
mode.
RESP
Coincidence
The patient’s heart rate and
respiration rate fall within 20% of
each other.
Observe the patient and treat, if necessary.
Check and change the electrode placement
if you receive a coincidence message until
you obtain a clear respiration signal.
RESP: Can’t
detect
coincidence
The RESP coincidence feature
is enabled but there is
excessive ECG artifact.
ECG leads maybe
disconnected.
Calm the patient.
Make sure the patient’s skin is properly
prepped.
Isolate the patient from auxiliary equipment.
Check the electrodes. Reapply gel or
change the electrode, if necessary.
Inspect and replace defective cables and
wires.
If a lead or electrode cannot be replaced,
select another lead for processing (from the
ECG menu).
RESP Signal
Saturated
RESP signal detected by
monitor has excessive baseline
shift.
Check the patient cable and lead wires
carefully.
Replace any cable or lead wire that is
suspect.
Reapply gel or change the electrode.
Check the M
ULTIMED pod and replace, if
necessary.
