Dräger Infinity Delta User Manual

B-26 DELTA/DELTA XL/KAPPA VF8
B T
ECHNICAL DATA
Infinity® PiCCO Pod
Relative humidity: Operating:
Hemo2, Hemo4, HemoMed: 20 to 90 %, non-condensing
MPod – QuadHemo: 10 to 95%
Storage: 10 to 95 % (with packaging)
Atmospheric pressure: Operating:
Hemo2, Hemo4, HemoMed: 525 to 795 mmHg
(70 to 106 kPa)
MPod – QuadHemo: 480 to 795 mmHg (64 to 106 kPa)
Storage: 375 to 795 mmHg (50 to 106 kPa)
User Interface
User Controls: Fixed keys (C.O. Start, IBP Zero)
Displays: four 4-character LCDs.
Connections: 4 invasive pressures, C.O., 2 temperatures, single cable
connecting pod to monitor
Degree of protection against ingress
of water:
IPX0 (per IEC 60529)
Physical Attributes
Size (H x W x D): 140 x 205 x 60 mm (5.5 x 8.1 x 2.3 in)
Weight: 0.9 kg (1.9 lb)
Note: Weight includes two transducer adapter blocks and exclude mounting clamp.
Electrical Specifications
Power source: Powered directly from the monitor
Protection against electric shock: Type CF
Mode of operation: Continuous
Defibrillation protection: Per IEC 601-2-34
Environmental Requirements
Temperature range: Operating:5 to 45 °C (41to 113 °F)
Storage: –20 to 60 °C (–4 to 140 °F)
Relative humidity: Operating:10to 95 %, non-condensing
Storage: 10 to 95 % (with packaging)
Atmospheric pressure: Operating:485 to 795 mmHg (65 to 106 kPa)
Storage: 375 to 795 mmHg (50 to 106 kPa)

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
