B-44 DELTA/DELTA XL/KAPPA VF8
B T
ECHNICAL DATA
Pulse Oximetry (Nellcor Oximax SpO
2
via Pod )
Low perfusion
performance:
(6)
Pulse amplitude:>0.02 %
Saturation (%SpO
2
):±2
and %transmission >5 %
Pulse rate:±3
(6)The Masimo SET® pod has been validated for low perfusion accuracy in bench top testing
against a Biotek Index 2 simulator and Masimo's simulator with signal strengths of greater than
0.02% and a % transmission of greater than 5% for saturations ranging from 70 to 100 %. This
variation equals plus or minus one standard deviation.
Parameter display: Saturation (%SpO
2
), pulse rate
Measurement range: %SpO
2
: 1 - 100%
Pulse rate:25 - 250 /min
Measurement accuracy, Adult mode (1, 2):
Saturation (%SpO2):
0 to 60% not specified
60 to 80% sensor-specific as follows:
Nellcor :
OxiMAX MAX-A, OxiMAX MAX-AL, OxiMAX MAX-P,
OxiMAX MAX-N, OxiMAX MAX-I, OxiMAX MAX-FAST ±3
Nellcor :
SC-A, MAX-R, OxiCliq A, OxiCliq P, OxiCliq N, OxiCliq I,
D-YS, DS-100A, OXI-A/N, OXI-P/I not specified
70 to 100% sensor-specific as follows:
Nellcor :
OxiMAX MAX-A, OxiMAX MAX-AL, OxiMAX MAX-P,
OxiMAX MAX-N, OxiMAX MAX-I, OxiMAX MAX-FAST
SC-A ±2
Nellcor :
OxiCliq A, OxiCliq P, OxiCliq N, OxiCliq I ±2.5
Nellcor :
D-YS, DS-100A, OXI-A/N, OXI-P/I ±3
Nellcor :
D-YS with D-YSE Ear Clip, D-YS with D-YSPD Spot Clip ±3.5
80 to 100% sensor-specific as follows:
Nellcor :
MAX-R ±3.5
Pulse Rate (3) : 25 - 250 bpm ±3 beats/min or ±3% (whichever is greater)
NOTES:
1) Since pulse oximeter measurements are statistically distributed, only about two-thirds of those
measurements can be expected to fall within ±1 A
rms
of the value measured by a co-oximeter.
2) The Infinity® Nellcor Oximax® SpO2 SmartPod™ pulse oximeter with Adult sensors has been
validated in human blood studies on healthy adult volunteers in induced hypoxia studies in the
range of 70-100% SpO2 against a laboratory co-oximeter and ECG monitor. This variation
equals ±1 A
rms
of the value measured by a co-oximeter.
3) The pulse rate accuracy has been validated on healthy adult volunteers during induced hypoxia
studies in the range of 70-100% SpO2 against a laboratory co-oximeter and ECG monitor. This
variation equals ±1 A
rms
of the pulse rate value measured by the ECG monitor.

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
