Dräger Infinity Delta User Manual

MONITORING S PECIFICATIONS
VF8 DELTA/DELTA XL/KAPPA B-45
tpO
2
/CO
2
Measurement accuracy, Neonatal mode (1, 2):
Saturation (%SpO2):
0 to 60% not specified
60 to 80% sensor-specific as follows:
Nellcor :
OxiMAX MAX-N ±3
Nellcor :
SC-PR, SC-NEO, OxiCliq N, D-YS, OXI-A/N not specified
70 to 100% sensor-specific as follows:
Nellcor:
Nellcor :
OxiMAX MAX-N, SC-PR, SC-NEO ±2
Nellcor :
OxiCliq N ±3.5
Nellcor :
D-YS, OXI-A/N ±4
Pulse Rate(3): ±3 beats/min or ±3% (whichever is greater)
NOTES:
1) Since pulse oximeter measurements are statistically distributed, only about two-thirds of those
measurements can be expected to fall within ±1 A
rms
of the value measured by a co-oximeter.
2) The Infinity® Nellcor Oximax® SpO2 SmartPod™ pulse oximeter with Adult sensors has been
validated in human blood studies on healthy adult volunteers in induced hypoxia studies in the
range of 70-100% SpO2 against a laboratory co-oximeter and ECG monitor. This variation
equals ±1 A
rms
of the value measured by a co-oximeter.
3) The pulse rate accuracy has been validated on healthy adult volunteers during induced hypoxia
studies in the range of 70-100% SpO2 against a laboratory co-oximeter and ECG monitor. This
variation equals ±1 A
rms
of the pulse rate value measured by the ECG monitor.
Nominal wavelength: Red: 660 nm
IR: 910 nm
Parameter display: tpO2, tpCO2 parameter values; plus selectable on oxy-
cardirespirogram
Sensing element: tpO2/tpCO2 solid-state, dual-thermistor electrode
Measurement range: tpO2: 0 to 800 mmHg
tpCO2: 0 to 200 mmHg
Resolution: 1 mmHg
Reporting interval: once every 1.2 s
Accuracy: tpO2: 40 to100 mmHg ±1 mmHg
<40 or >100 mmHg ±2 % or ±5 mmHg,
whichever is greater
tpCO2: 30 to 80 mmHg: ±1 mmHg
<30 or >80 mmHg ±3 mmHg
Drift: O2: ±5 % over recommended calibration interval
CO2: ±10 % over recommended calibration interval
Non-linearity: ±5 mmHg
Hysteresis: ±5 mmHg

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
