PeakVue frequency ranges
Frequency ranges
1 Hz 50 Hz 625 Hz
2 Hz 64 Hz 800 Hz
4 Hz 80 Hz 1 kHz
5 Hz 100 Hz 1.25 kHz
8 Hz 125 Hz 1.6 kHz
10 Hz 160 Hz 2 kHz
16 Hz 200 Hz 2.5 kHz
20 Hz 250 Hz 4 kHz
25 Hz 320 Hz 5 kHz
32 Hz 400 Hz 8 kHz
40 Hz 500 Hz 10 kHz
PeakVue Prefilters
Band-pass 20 -150 Hz High-pass 2 kHz
Band-pass 50 - 300 Hz High-pass 5 kHz
Band-pass 100 - 600 Hz Band-pass 5 - 6.5 kHz
Band-pass 500 -1 kHz High-pass 10 kHz
High-pass 500 Hz High-pass 20 kHz
High-pass 1 kHz
Demodulation
Demodulation uses a user-specified band-pass or high-pass filter to remove all low-
frequency components in the signal. The signal is amplified and amplitude demodulated,
which creates a low-frequency signal consisting of the envelope of the original signal. The
amplitude of the original signal is not maintained when demodulation is used.
Demodulation frequency ranges
The maximum frequency using the built-in demodulator is 5 kHz. The analyzer adjusts any
entered frequency to the next highest predefined frequency value.
Frequency ranges
10 Hz 400 Hz
20 Hz 500 Hz
50 Hz 1 kHz
100 Hz 2 kHz
Analyze and Advanced Analyze
122 MHM-97432 Rev 7
