10.13 Review Balance data
You can view the data collected or manually entered for any of the measurement runs in a
job. You cannot edit these values from the Review Data screen.
Procedure
1.
From the Balance main menu, press ALT > F9 Review/Edit Data.
The measurement run appears at the top of the screen. The speed also displays, if
you defined more than one for the job.
2. Select the following options. Some options may be unavailable if your job does not
have the appropriate data.
Option Description
F1 Select Runout View the runout data, if you collected the data.
F2 Select Ref. Run View the reference run data.
F3 Select Trial Run 1 View the data for trial run 1.
F4 Select Trial Run 2 View the data for trial run 2.
F5 Select Trial Run 3 View the data for trial run 3, if you collected the data.
F6 Select Trial Run 4 View the data for trial run 4, if you collected the data.
F8 Select Trim Run View the data for the last completed trim run. This option is
unavailable until you have trim run data.
Note
You cannot review data from previous or incomplete trim runs.
F9 Select Speed View a specific set of data for the selected speed. This option only
appears if you set up multiple speeds for your job in Advanced Balance
mode.
F10 Select Influ. Coef. View the influence coefficient data for completed trial runs. Influence
coefficients represent the system response at a specific measurement
point and plane to a known force. The analyzer uses magnitude (RMS)
and phase. Press F7 Select Review Data to return to the Review Data
screen.
F10 Toler. Check View the Tolerance Check data. This option displays only when you
selected a trim run and all the required data was acquired.
F11 Toggle Runout Display or hide runout data. This option only appears if you enabled
the runout measurement for your job in Advanced Balance mode.
F12 Edit Data Manually enter or modify balance data.
3. Press F7 Exit Review Data or Enter to return to the Balance main menu.
Balance
MHM-97432 Rev 7 343
