Option Description
F7 Filter Enable Enable or disable the filter option you select for the F8 Filter option.
F8 Filter Set the filter for the audio signal. You can select Bandpass, Highpass, or
Lowpass.
F9 Cutoff Select the frequency range for the filter type you chose for F8 Filter.
F10 Gain Increase the amplitude of the audio signal before broadcasting the signal
to the headphones. The signal gain affects the volume. You can also use
the up arrow key.
F11 Gain Decrease the amplitude of the audio signal before broadcasting the signal
to the headphones. The signal gain affects the volume. You can also use
the down arrow key.
F12 Stop or F12
Start
Stop or start broadcasting the audio to the headphones.
6.11 Redo a measurement in Analyze
1. From Manual Analyze or an Analysis Expert, select the desired measurement.
2.
Press Start or Enter.
The analyzer collects new data.
6.12 Store data to a route or an Analyze job
Unlike other programs on the analyzer, Analyze requires you to manually save the data
after a measurement completes. Other programs save data automatically.
Procedure
1.
After the measurement completes and the plot displays, press F9 Store Data.
If you opened Analyze from a route point, the data is saved to the route.
2. To save the data to a job, select or add a measurement in the job on the Current Job
screen.
3. Press F8 Store Data to Meas.
The measurement is labeled with the date, time, and type of measurement.
6.13 Review previously collected data in Analyze
Review Data shows the last data collected even if that data has not been stored. This data is
in the temporary memory and will be overwritten when new data is collected.
Analyze and Advanced Analyze
158 MHM-97432 Rev 7
