10.14 Manually enter data for a Balance job
You can manually enter or edit speed, magnitude, and phase information for a
measurement in a job. Modify values to review additional scenarios or enter data you did
not collect. The required measurements are displayed with the first measurement point
highlighted. Any changes you make are saved with the balance job.
Procedure
1.
From the Balance main menu, press ALT > F9 Review/Edit Data.
2. Select the desired measurement run.
The measurement run appears at the top of the screen.
3. Press F12 Edit Data.
4. Use the up and down arrow keys to select a measurement point.
5. Set the following options as necessary.
Option Description
F1 Edit Trial Run Wt. or F1
Edit Trim Run Wt.
Enter the weight values for the selected measurement run. These
options are available if you are editing a trial run or trim run.
F3 Edit Speed Enter the measurement speed between 0 and 100,000 RPMs.
F4 Edit Mag. Enter the magnitude between 0.0001 and 10,000 mils Pk-Pk.
Note
Magnitude readings within specification are not highlighted
green, as they are on the Review Data screen.
F5 Edit Phase Enter the phase value between 0 and 359 degrees.
6. Press F7 Select Review Data or Enter to return to the Review Data screen.
10.15 Calculator Mode
The Calculator Mode option lets you calculate solutions for special circumstances. This
option is outside the recommended program flow. You can access some modes from the
ALT keys, while other options are only available from within a job.
Calculator Mode Recommended use
Split Angle Calculate a new location for the weight. Use Split Angle if you cannot place a
weight at the calculated location in the balance correction. See
Section 10.15.1.
Balance
344 MHM-97432 Rev 7
