Option Description
High Alarm 2 The overall Fault value exceeded Dual Upper Absolute and Out of Window
Absolute alarms.
High Signal The signal is less than the upper validity limit of the sensor signal and
greater than the weak side value. In Dual Lower Delta alarms, the high
signal can occur when the baseline value plus the weak side value is
exceeded, but the value is less than the upper sensor validity range.
Low Alarm 1 For Dual Lower Delta type alarms, the baseline value minus the Alert value
was exceeded. For Dual Lower Absolute alarms, the Alert value was
exceeded.
Low Alarm 2 For Dual Lower Delta type alarms, the baseline value minus the Alert value
was exceeded. For Dual Lower Absolute alarms, the Fault value was
exceeded.
Low Signal Measured value is less than the weak side setup but greater than the lowest
valid signal level for a Dual Upper Absolute and Out of Window Absolute
type alarm.
Not Measured No measurements were made on this measurement point.
Notes You added a note. Other status messages may override the Notes message.
OK All measurements are within normal amplitude values.
Out Of Service You labeled equipment as out of service. No route data is collected, and the
out of service note is transferred with the route point.
Warning For DU-A type alarms, the baseline value was exceeded but has not reached
the alert level.
Window Alarm The measured values are outside the valid alarm window for an In Window
Absolute Alarm. This is used when a parameter must stay outside a set
range.
Vib Alarm One of the parameters exceeded an alarm level.
4.7 Notes
Notes let you make comments and observations about the equipment you are monitoring.
The analyzer saves notes with your measurement data. When you transfer the route to
AMS Machinery Manager, the note is included with the measurement point.
You can create up to 25 notes on the analyzer. You can also use pre-defined notes created
in AMS Machinery Manager that are included with the route. This lets you quickly add
common notes to a route. Notes are organized by groups, so you can scroll through
groups of similar notes.
4.7.1 Create a note in the analyzer
You can create and modify up to 25 notes in the analyzer. User-defined notes are stored in
internal memory, and they are not removed when you delete routes or route data.
Route
MHM-97432 Rev 7 91
