4. Press Enter.
5.
Press F6 Set Host Info.
6. Enter the host name or IP address of the PC the analyzer will connect to, and set the
Host Port ID to 10077.
7. Press Enter.
8. On the analyzer, open a program and select Connect For Transfer using a path below.
Choose the program that corresponds to the file type you want to transfer.
Program Key sequence to Connect for Transfer option
Analyze Home > F7 Analyze > ALT > F9 Connect For Transfer
Balance Home > F9 Balance > F12 Job Manager > F7 Connect For Transfer
ODS/Modal Home > F12 ODS/Modal > F8 Job Manager > F7 Connect For Transfer
Program Manager Home > F6 Program Manager > F8 Connect For Transfer
Route Home > F8 Route > ALT > F9 Route Mgnt > F7 Connect For Transfer
Laser Alignment Home > F10 Adv. Laser Align > ALT > F9 Job Manager > F7 Connect
For Transfer
Transient Home > F11 Adv. Transient > F8 Job Manager > F7 Connect For
Transfer
B.5 View the version number of the CSI 2140
Remote Display Viewer
1. Open the CSI 2140 Remote Display Viewer (2140RemoteHost.exe) on your PC.
2.
Select a connection type and click OK.
3. Click Help > About CSI 2140 Remote Display Viewer.
The version number and build date are displayed.
4. Click OK.
View and control your CSI 2140 from a PC
382 MHM-97432 Rev 7
