Page #188 background imageLoading...
Page #188 background image
The battery status LED on the laser or sensor lights steady green when the battery is
fully charged. See the following table for more information.
Activity Battery status LED - Laser Battery status LED - Sensor
Charging Blinks green when the battery is charging
Lights steady green when fully charged
Lights red when a failure occurs during charging
Switched on
(in operation)
Lights up green for 3 seconds when battery run time is greater than 10
hours
Blinks green every 3 seconds when
battery run time is between 5 – 10
hours
Blinks green every 3 seconds when
battery run time is between 1 – 5
hours
Blinks red every 3 seconds when
battery run time is between 1 – 5
hours
Blinks red every 3 seconds when
battery run time is insufficient for
longer measurements
Blinks red constantly when battery run time is less than 1 hour
7.2.10 Update the sensor firmware
If the firmware file is the same version as firmware installed on the sensor, the option to
update the firmware is not available.
Prerequisites
Ensure the sensor is turned on and paired with the analyzer.
Procedure
From the Laser Align Application main menu, press ALT > F8 Head Config > F5 Check Head
Status > F1 Show Versions > F7 Update Sensor Firmware.
7.3 Manage jobs
7.3.1 Job Manager
From the Job Manager screen, you can perform job related tasks such as creating, editing,
deleting, transferring, copying, and activating jobs.
To go to the Job Manager screen, press ALT2 on the Laser Align Application main menu and
press F9 Job Manager.
Advanced Laser Alignment
182 MHM-97432 Rev 7
