Option Description
F9 Job Manager Perform job-related tasks such as creating, activating, copying, or editing
a job.
This is also where you can select the Connect for Transfer button that
enables you to transfer jobs between the analyzer and the PC.
F10 Intentionally blank.
F11 Intentionally blank.
F12 Job Reset Reset the job data by clearing all stored data or by loading default values.
7.2 Set up the laser and sensor
7.2.1 Laser and sensor overview
The laser and sensor communicate via Bluetooth with the analyzer.
The laser and sensor have a similar appearance and are differentiated by the color of their
sliding dust caps—yellow for the laser and red for the sensor. To turn on the laser and
sensor, briefly press and hold the on/off button.
Terminology
The following terminologies are used throughout this document:
Term Meaning
Laser Refers to the laser head (yellow dust cap)
Sensor Refers to the sensor head (red dust cap)
Laser fixtures Refers to both the laser and sensor heads
The laser
The laser beam is adjusted during set-up by changing its vertical and horizontal angles
using the position thumbwheels, so that the beam strikes the sensor lens perpendicular to
the lens surface.
WARNING!
Do not stare into the laser beam when the laser is turned on. The semiconductor laser
diode emits a ray of red light (wavelength 635 nm) that is visible where it strikes a
surface. The Class 2 laser beam is emitted with a diameter of approximately 5 mm
(3/16”).
Do not insert any optical devices into the beam path.
Advanced Laser Alignment
MHM-97432 Rev 7 171
