10.11 Notes
Notes let you make comments and observations about the equipment you are monitoring.
After you add the note to the job, it is saved with your measurement data. When you
transfer the job to AMS Machinery Manager, the note is included.
The analyzer has pre-defined notes you can use. Notes are organized by groups, so you can
scroll through groups of similar notes.
Note
You cannot modify a note you created. If you need to modify it, delete the note and create a new
one.
10.11.1 Create a note in the analyzer
You can have up to 25 user-defined notes. If you try to add more, you must delete a note
before adding a new note.
Note
Notes you create are stored in the analyzer until you delete them. They are not removed when you
delete a job.
Procedure
1.
From the Balance main menu, press ALT > F3 Notes > F2 User Defined Notes > F1 Create
User Note.
2. Enter up to 32 characters for the note.
3. Press Enter.
The new note appears under the User Defined Notes section on the Notes screen.
10.11.2 Add a note to a Balance job
You can add up to 40 notes per job.
Procedure
1. From the Balance main menu, press ALT > F3 Notes.
2. Use the up and down arrow keys to select a predefined note, or press F2 User Defined
and select a note you created. For predefined notes, press F1 Prev Group or F7 Next
Group to scroll through the predefined notes.
3. Press F3 Add To Job.
The selected note appears under the Assigned Notes section at the bottom of the
screen. The Balance main menu also displays the number of notes in the upper right
corner of the screen.
Balance
MHM-97432 Rev 7 339
