10. Use the analyzer's touchscreen, hard keys, or the PC mouse to select menu options
or enter alphanumeric text.
Note
If the analyzer enters standby or is powered off, the analyzer disconnects from the CSI 2140
Remote Display Viewer. Ensure your standby timer is properly set for your tasks.
11. To close the CSI 2140 Remote Display Viewer, press Home > F5 Comm Setup > ALT > F5
Remote Display Stop, and then close the PC program (2140RemoteHost.exe).
B.4 Transfer files while using the CSI 2140 Remote
Display Viewer
You can transfer files between the analyzer and AMS Machinery Manager while you use the
CSI 2140 Remote Display Viewer. However, you cannot use the USB connection type to
simultaneously transfer data and display the CSI 2140 to the CSI 2140 Remote Display
Viewer on your PC.
To use Ethernet/Wireless to simultaneously communicate with CSI 2140 Remote Display
Viewer and AMS Machinery Manager Data Transfer, do not use the same Host Port ID for
both programs. 10078 is the default ID for communication with the CSI 2140 Remote
Display Viewer, and 10077 is the default value for communication with AMS Machinery
Manager.
To set the Host Port ID on the analyzer for CSI 2140 Remote Display Viewer, press Home >
F5 Comm Setup > ALT > F6 Remote Host Info > F6 Set Host Port. To set the Host Port ID on the
analyzer for AMS Machinery Manager Data Transfer, press Home > F5 Comm Setup > F6 Set
Host Info > F6 Set Host Port.
Example setup
Do the following to use USB to connect to CSI 2140 Remote Display Viewer, and Ethernet
to connect to AMS Machinery Manager Data Transfer.
To set up the USB connection for the CSI 2140 Remote Display Viewer:
1.
Connect the USB cable to the analyzer and your PC.
2. On your PC, open the 2140RemoteHost.exe.
3. Select USB as the connection type, and click Enter.
4. On the analyzer, press Home > F5 Comm Setup > ALT > F3 Remote Display Port.
5. Select USB.
6. Press F4 Remote Display Start.
To set up the Ethernet connection for AMS Machinery Manager Data Transfer:
1. Connect the analyzer to the network using the Ethernet cable.
2. On the analyzer, press Home > F5 Comm Setup > F1 Set Connect Port.
3. Select Ethernet.
View and control your CSI 2140 from a PC
MHM-97432 Rev 7 381
