5. Press Enter.
8.3.3 Set data units in Advanced Transient
Set the data units for each selected input.
Procedure
1.
Activate a job.
2. From the Transient main menu, press F1 Setup / Acquire Data > F12 Input Setup.
3. For each input, select the units.
4. Press Enter.
8.4 Tachometers
8.4.1 Set up a tachometer in Advanced Transient
Note
By default, the analyzer is set up to use the CSI 404 tachometers. The analyzer supports
tachometer/RPM measurements up to 100,000 RPM.
Procedure
1.
From the Transient main menu, press ALT > F4 Tach Setup or press F1 Setup / Acquire
Data > F7 Tach Setup.
The Tachometer Setup screen appears.
2. Set the following options as necessary.
Option Description
F2 Pseudo Tach Enable Pseudo Tach for time synchronous averaging or order tracking
intermediate shafts in gearboxes that cannot be accessed directly. Use the
Pseudo Tach to produce the turning speed signal. The analyzer uses the
following formula: (Incoming tachometer frequency) X ((tach frequency X
the number of teeth on the tached shaft)/number of teeth on the pseudo
shaft). Disable Pseudo Tach when you can use the tachometer directly on a
shaft. The default is Disabled.
F3 Tached Shaft (Only available when Pseudo Tach is enabled.) If the reflective tape is on the
input shaft, enter the number of teeth on the tached shaft, which is the
shaft with the tachometer. The default is 1.
F4 Pseudo Shaft (Only available when Pseudo Tach is enabled.) Enter the number of teeth on
the internal shaft. The analyzer calculates the pseudo tach frequency based
on the number of teeth specified for the tached shaft and pseudo shaft.
The default is 1.
Advanced Transient
MHM-97432 Rev 7 265
