9.7 Collect ODS/Modal data
Note
If you cancel data collection, the existing data is not overwritten. After data is stored on a
measurement point, you can copy it to other measurement points using the Copy Data option.
Procedure
1.
Activate a job.
2. Ensure the job parameters are set as desired.
3. Connect the sensor to the analyzer and equipment to measure.
4. From the ODS/Modal main menu, use the up and down arrow keys to select a
measurement point.
5. Press F2 XYZ to select a measurement direction for the point.
The directions that are collected together are highlighted red.
6. Press F1 Start.
If the measurement direction already has data stored, the analyzer prompts you to
overwrite the data. Measurement directions with data are highlighted green. The
defined plots appear.
Note
Press F2 Next Input Response to display the data for the next response input, if you set up more
than two inputs.
7. Press the Enter key to return the ODS/Modal main menu to collect data for other
measurement points.
8.
Repeat the steps above until all points have data.
Postrequisites
When you transfer the job to AMS Machinery Manager, only measurement points with
data are transferred.
9.7.1 View all unmeasured points for the ODS/Modal job
A red box appears around the current measurement point when more than one
measurement point is displayed in the matrix. The direction of the current measurement
point is red.
If you stored data on a point, the analyzer highlights the measurement directions points
with data.
Procedure
1. Activate a job.
ODS/Modal
292 MHM-97432 Rev 7
