Option Description
F10 Change Y Axis
Type
Set the amplitude axis type. Not applicable for the Balance program.
The default is Linear.
F11 Change X Axis
Type
Set the frequency axis type. Not applicable for the Balance program.
The default is Linear.
F12 Change Hz \ CPM Set the frequency to Hz Units (Hertz) or CPM Units (cycles per minute).
The default is Hz Units.
3. Press Enter.
2.15 Memory card
You can insert a memory card into the analyzer to store route or job files. You may want to
store some routes or jobs on specific cards to stay organized.
Note
For optimal performance, use a SD memory card with a speed class of 10 or higher. To verify the
speed class of your memory card, refer to the label on the memory card or the documentation for
the memory card.
The memory card slot is located under the battery pack on the back of the analyzer. You
must remove the six screws to remove the battery pack and access the memory card slot.
You can use the File Utility to add, copy, move, or delete files from the inserted memory
card.
2.15.1 Insert or remove a memory card
WARNING!
• Insert or remove memory cards only when the analyzer is turned off.
• Remove the battery pack only in a non-hazardous area.
Procedure
1. Ensure the power supply is disconnected from the analyzer.
2. Remove the battery pack from the back of the analyzer. See Section 2.7.6.
3. To insert a memory card, press the memory card, with the metal contacts facing up,
into the memory card slot until it clicks.
Introduction to the analyzer
32 MHM-97432 Rev 7
