Procedure
1.
Press Home > ALT > F3 Set Time.
2. Set the following options.
Option Description
F2 Set Local Time Enter values for the time and date. Use the arrow keys to go to the
next value.
F5 Date Display Format Select the format used for the date.
F6 Time Display Format Select the 12 or 24 hour time format.
F9 Set Time Zone Select the time zone. If the time zone uses Daylight Savings Time, the
analyzer automatically adjusts the time and notifies you of the
change.
3. Press Enter.
2.14.8 Set the default display units
You can set the default display units for measurements and plots. You can also select
English, SI, or metric units, and the X and Y axis types for graphs.
Note
You can overwrite only the X and Y axes while in other programs.
Procedure
1.
Press Home > F4 Set Display Units.
2. Use the up and down arrow keys to select an option.
Option Description
F2 Set Accel Set the acceleration type. Not applicable for the Balance program.
The default is RMS.
F3 Set Veloc Set the velocity units. Not applicable for the Balance program. The
default is Peak.
F4 Set Displace Set the displacement units. Not applicable for the Balance program.
The default is Peak to Peak.
F5 Set Non Standard Set the non-standard data types. Not applicable for the Balance
program. The default is RMS.
F6 Set Units Set to English Units, Metric Units, or SI Units. The default is English Units.
F8 Set dB Ref Configure acceleration, velocity, displacement, non-standard, and
microphone measurements displays for decibel reference. Enter a
value between 0.000000001 and 2. Not applicable for the Balance or
Route programs. The dB reference values are loaded with the route.
Introduction to the analyzer
MHM-97432 Rev 7 31
