The laser is water and dust resistant (IP 65). The internal optics and electronics are
internally sealed, preventing possible contamination.
The laserFigure 7-6:
The sensor
The sensor contains two position detectors that measure the exact position and inclination
of the laser beam as the shafts are rotated.
Bluetooth technology is integrated into the sensor for wireless transmission of
measurement data to the analyzer.
Advanced Laser Alignment
172 MHM-97432 Rev 7
