8.2.5 Change the equipment description for an Advanced
Transient job
1. From the Transient main menu, press F8 Job Manager.
2.
Use the up and down arrow keys to select a job.
3. Press F4 Edit This Job > F2 Edit Equip Desc.
4. Enter up to 28 characters.
5. Press Enter.
8.2.6 Edit the measurement ID or description for an Advanced
Transient job
1. From the Transient main menu, press F8 Job Manager.
2. Use the up and down arrow keys to select a job.
3. Press F4 Edit This Job, and use the up and down arrow keys to select a measurement.
4. Press F5 Edit Meas, and set the following options as necessary.
Option Description
F2 Edit ID Enter up to three characters to identify the measurement point for input 1.
F3 Edit ID Enter up to three characters to identify the measurement point for input 2.
F4 Edit ID Enter up to three characters to identify the measurement point for input 3.
F5 Edit ID Enter up to three characters to identify the measurement point for input 4.
F6 Edit Desc Enter up to 20 characters to describe the equipment.
5. Press Enter.
8.2.7 Add a measurement to an Advanced Transient job
From the Transient main menu, press F4 Add New Meas or F8 Job Manager > F4 Edit This Job >
F4 Add Meas.
A measurement labeled "No Data" appears in the job. The setup for the new measurement
point is not defined. When you collect data, the setup is the same as the last acquisition or
the setup from the last reviewed acquisition.
8.2.8 Delete a measurement from an Advanced Transient job
1. From the Transient main menu, press F8 Job Manager > F4 Edit This Job.
2.
Use the up and down arrow keys to select a measurement.
3. Press F6 Delete Meas.
4. Press Enter.
Advanced Transient
262 MHM-97432 Rev 7
