Note
The selections may be limited by the number of points. The analyzer only displays the points
with data.
The default is 512.
4.
Press Enter.
8.5.2 Set the number of lines in Advanced Transient
You can select the number of lines to display.
Procedure
1. Activate a job.
2. From the Transient main menu, press ALT > F5 Data Display Settings > F3 Set Lines.
3. Use the up and down arrow keys to select an option.
The selections are limited by the number of lines (number of samples divided by
2.56) to collect. The default is 200.
4. Press Enter.
8.5.3 Set the window in Advanced Transient
The window applies a shaping function to the waveform signal before computing the
spectrum.
Procedure
1. Activate a job.
2. From the Transient main menu, press ALT > F5 Data Display Settings > F4 Set Window.
3. Press F4 Set Window until the desired option is selected.
Option Description
Hanning Smooths end effects and reduces leakage in the spectrum. Use this for normal
analyzer operation.
Uniform Does not apply any shaping and is subject to leakage and amplitude errors.
4. Press Enter.
8.5.4 Set the spectrum units in Advanced Transient
Specify the units for the analyzer spectrum only. If the data was converted to velocity units
during acquisition, the only choices are velocity and displacement. If the data was
converted to displacement units during acquisition, displacement units must be used.
Advanced Transient
268 MHM-97432 Rev 7
