10.5.2 Add a measurement point to a Balance job
You can add up to three measurement points for a measurement plane. The points are
added at the end of the list.
Note
This is available only in Advanced Balance mode.
Procedure
1.
From the Balance main menu, press F3 Job Setup.
2. Press Enter or F4 Meas. Plane Setup.
The Measurement Plane Setup screen appears.
3. Ensure the correct measurement plane displays at the top of the screen.
Press Enter or F2 Select Meas. Plane to advance to the next measurement plane, if
necessary.
4. Press F7 Add MPT.
The measurement point appears in the table with a default ID, angle, channel, and
symbol.
10.5.3 Delete a measurement point from a Balance job
You can delete any measurement point on a measurement plane, but you must have at
least one point per measurement plane.
Note
This is available only in Advanced Balance mode.
Procedure
1.
From the Balance main menu, press F3 Job Setup.
2. Press Enter or F4 Meas. Plane Setup.
The Measurement Plane Setup screen appears.
3. Ensure the correct measurement plane displays at the top of the screen.
Press Enter or F2 Select Meas. Plane to advance to the next measurement plane, if
necessary.
4. Use the up and down arrow keys to select a measurement point.
5. Press F8 Delete MPT.
The measurement point is deleted.
Balance
318 MHM-97432 Rev 7
