218 Epson FX-100 Control Commands
ESC B Set Multiple Vertical Tabs
ASCII:
ESC B (n1)...(n16) NUL
Control:
CTRL
[ B (n1)...(n16)
CTRL
@
Decimal:
27 66 (n1)...(n16) 0
Hexadecimal:
1B 42 (n1)...(n16) 00
Sets vertical tabs to the specified lines. Note that this control command is
terminated with a null byte. n denotes the line number for each tab. The
valid entries for n are from 2 to the bottom line on the page, as specified
by the form length setting. Send the values of n in ascending order. An
out of order tab value is interpreted as a terminator.
The tab positions set by ESC B are the same as those set by ESC b (0),
vertical tab channel zero.
ESC B and ESC b clear all existing vertical tabs. Therefore, to add one
tab, you must include all existing tabs, plus the new one. Use ESC B or
ESC b to set the tabs. Use the Vertical Tab control code, VT, to cause
the printer to tab to each subsequent tab.
Example
REM SET VERTICAL TABS TO LINES 5 TO 10
LPRINT CHR$(27);"B";CHR$(5);CHR$(10);CHR$(0);
ESC b Set Vertical Tab Channel
ASCII:
ESC b (m) (n1)...(n16) NUL
Control:
CTRL
[ b (m) (n1)...(n16)
CTRL
@
Decimal:
27 98 (m) (n1)...(n16) 0
Hexadecimal:
1B 62 (m) (n1)...(n16) 00
Sets vertical tabs to the specified lines for the vertical tab Channel m.
Note that this control sequence is terminated with a null byte. m denotes
the tab channel. The valid entries for m are 0 to 7. n denotes the line
number for each tab. The valid entries for n are from 2 to the bottom line
on the page, as specified by the form length setting. Send the values of n
in ascending order. An out of order tab value is interpreted as a
terminator.
Note
: The tab positions for Channel 0 can also be set with ESC B.
