A-14 Appendix A—Specifications
Size and Print Area:
B
D
A
CE
F
Symbol Description Specification
A Form Length
*
0.5 to 31.5 in. (approx. 12.7 to 800 mm) in ½ in.
inc.
B Paper Width 3 to 16 in. (approx. 76.2 to 406.4 mm)
C 1st Character Column 0.55 to 0.88 in. (approx. 14 to 22.35 mm)
D Vertical Sprocket Spacing 0.50 in.
E Print Area 13.6 in. (approx. 342.9 mm), max.
F Horizontal Sprocket
Position
0.25 in. or 6.00 mm
*
Form length as selected in the configuration menu. The actual paper length is continuous. Longer form lengths
and a No Form mode are available in some emulations.
