CONFIDENTIAL
Paper roll Character commands ESC &
Ver. 10.01 p. 115
■ A user-defined character, downloaded graphics, and downloaded bit image cannot be defined
simultaneously on some printer models.
• When this command is executed, the downloaded bit image is cleared.
• When GS(L <Function 83> <Function 84> or GS ✻ is executed, the user-defined character data is
cleared.
■ Once the user-defined characters have been defined, they are available until ESC ?, GS ✻, or ESC @ is
executed; the user-defined characters are redefined; the power is turned off; or the printer is reset.
■ Some models clear user-defined character data when executing GS ( L <Function 83>, <Function 84>, or
GS ✻.
■ The user-defined characters are not defined at the default, and the resident characters are printed.
■ The relationship between the definition data and printing result is as follows.
Example: Downloaded character definition consists of 9 × 7 dots.
[Model-dependent variations] TM-J2000/J2100, TM-T90, TM-T88III, TM-L90, TM-L60II, TM-U230, TM-U220,
TM-U210, TM-U300A/B
See program example and print sample for ESC %, ESC &, and ESC ?.
TM-J2000/J2100
Only the MSB can be printed in the third byte for vertical direction of Font B of other than
Japanese model. A user-defined character, downloaded graphics, and downloaded bit image
cannot be defined simultaneously.
d1 d3 d5 d7 d9 d11 d13
MSB
LSB
d2 d4 d6 d8 d10 d12 d14
MSB
LSB
To Next Page
