A
Indicates items that have been setup for the printer as icons. Select each icon to check the current settings or access
each setting menu.
B
Displays each menu. You can add or change the sequence.
C
Indicates an ongoing job and the printer's status. Select message to display the Job/Status menu.
Displays the date and time when the printer is not working or there are no errors.
D
Switch tabs.
E
Indicates the setting items. Select each item to set or change the settings.
The grayed out items are not available. Select the item to check why they are unavailable.
F
Execute the current settings. Available functions vary depending on each menu.
Icons displayed in the LCD Screen
e
following icons are displayed on the LCD screen depending on the printer's status.
Displays the Printer Status screen.
You can check the approximate ink levels and the approximate service life of the maintenance box.
Indicates the network connection status.
Select the icon to check and change the current settings. This is the shortcut for the following menu.
Settings > General Settings > Network Settings > Wi-Fi Setup
The printer is not connected to a wired (Ethernet) network or unset it.
The printer is connected to a wired (Ethernet) network.
The printer is not connected to a wireless (Wi-Fi) network.
The printer is searching for SSID, unset IP address, or having a problem with a wireless (Wi-Fi)
network.
The printer is connected to a wireless (Wi-Fi) network.
The number of bars indicates the signal strength of the connection. The more bars there are, the
stronger the connection.
The printer is not connected to a wireless (Wi-Fi) network in Wi-Fi Direct (Simple AP) mode.
The printer is connected to a wireless (Wi-Fi) network in Wi-Fi Direct (Simple AP) mode.
User's Guide
Printer Basics
22
