Rear View
1 Registration Roller 2 OPC Drum
3Levers 4ADF Cover
5Ethernet Port 6USB Port
7 Paper Chute 8 Transfer Roller
9 Power Connector 10 Rear Cover Handle
11 Rear Cover 12 Phone Connector
13 Wall Jack Connector
Automatic Document Feeder (ADF)
AL-MX200 Series User’s Guide
Basic Operation 27
