Connection Type Connection Specifications
Ethernet 10 Base-T/100 Base-TX compatible
USB USB 2.0 compatible
Wireless (AL-MX200DWF only) IEEE 802.11b/802.11g
Wall Jack Connector RJ11
Phone Connector RJ11WAll
1Ethernet Port
2USB Port
3 Wall Jack Connector
4 Phone Connector
Connecting Printer to a Computer or a Network
Connect your printer via a USB, Ethernet, or wireless (AL-MX200DWF only) connection. Hardware
and cabling requirements vary for the different connection methods. Ethernet cables and hardware
are not supplied with your printer and must be purchased separately.
The available features for each connection type are shown in the following table.
AL-MX200 Series User’s Guide
Printer Connection and Software Installation 40
