3025EMC Master Control Switching & Channel Branding
Revision 3.0.3 Page 183
Keyer 4 On-Air
N/A
Toggles the on-air
state if the selected
keyer.
N/A
Keyer Gain Up
Current Keyer or
Specified Keyer.
Adjust the Selected
Keyer Gain Up OR the
C
urrent keyer (see
“Keyer” button type)
Gain Up.
If this button is
configured directly
above a rotary dial then
this button configures
the function of this dial
as Keyer Gain
Up/Down.
Keyer Gain Down
Current Keyer or
Specified Keyer.
Adjust the Selected
Keyer Gain Up OR the
C
urrent keyer (see
“Keyer” button type)
Gain Up.
If this button is
configured directly
above a rotary dial then
this button configures
the function of this dial
as Keyer Gain
Up/Down.
Keyer Clip Up
Current Keyer or
Specified Keyer.
Adjust the Selected
Keyer Clip Up OR the
Current keyer (see
“Keyer” button type) Clip
Up.
If this button is
configured directly
above a rotary dial then
this button configures
the function of this dial
as Keyer Clip Up/Down.
Keyer Clip Down
Current Keyer or
Specified Keyer.
Adjust the Selected
Keyer Clip Up OR the
Current keyer (see
“Keyer” button type) Clip
Up.
If this button is
configured directly
above a rotary dial then
this button configures
the function of this dial
as Keyer Clip Up/Down.
Keyer Key Type
Modes
Select the mode for the
currently selected keyer.
N/A
Keyer
Scrolling or specified
keyer.
Select the current keyer
that will be adjusted.
N/A
Keyer Transparency
Up
Current Keyer or
Specified Keyer.
Adjust the Selected
Keyer Transparency Up
OR the Current keyer
(see “Keyer” button
type) Clip Up.
If this button is
configured directly
above a rotary dial then
this button configures
the function of this dial
as Keyer Transparency
Up/Down.
Keyer Transparency
Down
Current Keyer or
Specified Keyer.
Adjust the Selected
Keyer Transparency Up
OR the Current keyer
(see “Keyer” button
type) Clip Up.
If this button is
configured directly
above a rotary dial then
this button configures
the function of this dial
as Keyer Transparency
Up/Down.
