7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
HTML Revision 1.4 Page 5-9
bottom
source
router
mode
offset
threshold
gain
nonpcm
line21_protect
b_blanking
Individual object constructs
object bus_setup (“bus names”)
{
object channel (“channel names”)
{
source = “audio_source_name”
gain = “gain_db”
router = “1”, …, “12”, “none”
nonpcm = “1” or “0”
}
}
"
Source, gain, and router do not have to be specified all in one object. Left and right
channels are routed in pairs. As a result, the latter router definition for a pair
overrides the earlier one if there is any.
nonpcm is not implemented in current version
bus names
“black”
“white”
“1”, “2”, “3”, “4”, “5”, “6”, “7”, “8”, “9”, “10”, “11”, “12”
channel names
“1L”, “1R”, “2L”, “2R”, “3L”, “3R”, “4L”, “4R”
audio_source_names
AES1L, AES1R, AES2L, AES2R,
AES3L, AES3R, AES4L, AES4R,
AES1M, AES2M, AES3M, AES4M,
EMB1L, EMB1R, EMB2L, EMB2R,
EMB3L, EMB3R, EMB4L, EMB4R,
EMB1M, EMB2M, EMB3M, EMB4M
Silence
