7700 Multiframe Manual
7725DSK-LG / 7725DSK-LG-HD HD/SD Logo Inserter & Media Keyer
Page 5-10 Revision 1.4 HTML
object router()
{
pgm_source = “bus_name”
PRV_source = “bus_name”
key_source = “bus_name”
fill_source = “bus_name”
}
"
Values for bus_name are the same as for object bus_setup.
key_source and fill_source are not implemented in the current version.
object transition()
{
type = “transition type”
rate = “integer number of fields”
swap = “1” or “0”
}
"
Note: “1” to enable swap.
transition type
Cut, Fade,
BarWipeTopToBottom, DiagonalWipeTopLeft,
BarWipeLeftToRight, DiagonalWipeBottomLeft,
BarWipeBottomToTop, DiagonalWipeBottomRight,
BarWipeRightToLeft, DiagonalWipeTopRight,
BoxWipeBottomLeft, BoxWipeBottomRight,
BarnDoorWipeVerticalClose, BarnDoorWipeHorizontalClose,
BarnDoorWipeVerticalOpen, BarnDoorWipeHorizontalOpen,
IrisWipeRectangleClose, IrisWipeRectangleOpen,
IrisWipeCircleClose, IrisWipeCircleOpen,
IrisWipeDiamondClose, IrisWipeDiamondOpen,
CutFade, FadeFade, FadeCut
object matte()
{
enable = “1” or “0”
top = “integer number of lines”
bottom = “integer number of lines”
}
"
Note: “1” to enable matte.
