Move, rotate and zoom in or out on the graphic.
11.2 Move, rotate and zoom in or out on the graphic.
When no option has been selected on the softkey menu, it is possible to act upon the graphic
as follows.
Move the graphic.
To move the part of the active view, move the mouse while holding its right button or use the
following keys.
Rotate the graphic.
To rotate the part of the active view, move the mouse while holding its left button or use the
following keys [[][][][].
Zoom the graphic.
To zoom in or out on the active view, turn the mouse wheel or use the [+][-] keys.
Key. Meaning.
Move the part to the left or to the right.
Move the part up or down.
ENDHOME
