·74·
Operating manual
CNC 8070
4.
AUTOMATIC MODE
(REF: 1505)
Program simulation and execution.
4.3.2 Select the first and last blocks of the execution.
The horizontal softkey menu shows the following options to set the first and last blocks of
execution.
First block.
This option sets as starting block for execution the block selected with the cursor. When not
setting the starting block, the program will begin executing from the first block.
The first block may be selected using the cursor or the "Find text" option of the softkey menu.
The selected block stays active until canceled (selecting another block or selecting the same
one again) or executing the program.
Stop condition.
This option sets the block where the execution of the program or subroutine will be
interrupted. After executing that block, the execution may be resumed with the [START] key
or canceled with the [RESET] key. If the last block is not set, the program execution will end
executing one of the end-of-program functions "M02" or "M30".
Select subroutine.
This option selects the stop condition in a global subroutine which has been called upon from
the program. When selecting this option, the CNC shows a list of the available subroutines.
After selecting the desired subroutine, it will appear in the program window.
Last block.
This option sets as execution interruption block the block selected with the cursor. If the last
block is not set, the program execution will end executing one of the end-of-program functions
"M02" or "M30".
The last block may be selected using the cursor or the "Find text" option of the softkey menu.
The selected block stays active until canceled (selecting another block or selecting the same
one again) or executing the program.
Number of times.
This option sets as stop condition, that the block selected as the last block has been executed
a specific number of times.
When selecting this option, the CNC requests the number of times that the block must be
executed before ending the execution of the program. After entering the number of times,
press [ENTER] to validate the value or [ESC] to cancel it.
Softkey. Description.
First block. Starting block for execution.
Stop condition. Set the condition for ending the execution.
Automatic block search. Searching a block.
Find text. Find text.
When selecting this option, the softkey menu of the CNC shows the options available for
selecting the stop condition. To return to the main menu, press the [BACK] key.
